PowerBrick SC Sales AreaCentral Asia Diversion Control Check
PowerBrick SC
- 16.07kWh - 803.84kWh
- Support 50 parallel units
PowerBrick SC is a low-voltage product designed for household energy storage scenarios with a stylish and elegant appearance. lt uses a high-capacity 314 Ah battery to support 50 parallel units with a capacity range from 16.07kWh to 803.84kWh. lt provides a highly safe, reliable, intelligent and friendly experience. Built-in display screen, check the battery status at any time.
Product Features
-
Flexible Expansion
Up to 50 units in parallel, 16.07 kWh - 803.84 kWh capacity -
Automatic Self-heating
-20°C to 55°C operating temperature (optional) -
Ultra Safe
Intelligent fire extinguishing system,detects and extinguishes fire in 5s -
Easy Installation
Flexible wall or floor mounting, easily moved by one person on wheels -
Long-term Reliability
LFP cells, 8000+ cycles, 10 years warranty -
Smart Management
Built-in display for battery status, with real-time monitoring, remote control, and OTA updates
Technical Specifications
-
Product Model PowerBrick SC Battery Type LiFePO4 Nominal Battery Energy 16.076 kWh Cycle Life ≥8000 cycles
Protection Level IP20 Net Weight 116Kg Dimension[W*D*H] 435*233*857mm Maximum Parallel Modules 50
FAQ
-
Q: How can I purchase Dyness PowerBrick SC in Pakistan or other markets?
A: Dyness PowerBrick SC is generally available through authorized Dyness distributors, installers, and local partners. Customers interested in purchasing Dyness PowerBrick SC should provide their country, city, required quantity, and application requirements so they can be connected with an appropriate local partner.
-
Q: Where can I find the installation manual and compatibility documents for Dyness PowerBrick SC?
A: The user manual, datasheet, installation guide, compatibility list, and other available documents for Dyness PowerBrick SC can be viewed and downloaded from the Dyness Download Center: https://www.dyness.com/download.
-
Q: How much space is required to install Dyness PowerBrick SC on a wall?
A: The wall installation space for Dyness PowerBrick SC should meet the clearance, ventilation, mounting-surface, and maintenance requirements specified in the official installation manual. Installation should be completed by a qualified professional on a wall that can safely support Dyness PowerBrick SC.
-
Q: Can Dyness PowerBrick SC operate without an internet connection?
A: Yes, Dyness PowerBrick SC can continue charging, discharging, and communicating with a compatible inverter without an internet connection. The lack of internet access does not affect the normal local operation of Dyness PowerBrick SC, although remote monitoring and online services may be unavailable.
-
Q: Is Dyness PowerBrick SC compatible with Deye and other mainstream inverter brands?
A: Dyness PowerBrick SC is compatible with selected Deye and other mainstream low-voltage inverter models. Compatibility depends on the complete inverter model, communication protocol, firmware version, and system configuration. Users should check the latest official compatibility list before connecting Dyness PowerBrick SC to an inverter.
