DH200F

PV+ESS All-in-one Cabinet

All-in-one design, integrated with PV. ESS and D.G., smart air-cooled heat dissipation, single cabinet capacity of 215kWh. Suitable for industrial and commercial scenarios, which supports functions like timed scheduling, peak-shaving, PV self-generation & consumption and so on.

Buy Now >
Battery Specifications
Battery Type LFP (LiFePO4)
Battery Capacity 280Ah
PACK Configuration 1P16S
PACK Quantity 15 PACK/Cluster
Rated Current 140A
Max. Current 160A
Voltage Range 672~864Vdc
Nominal Capacity 215kWh
AC(on-grid)
Rated Power 100kW
AC Maximum Current 167A
AC Rated Voltage 400Vac
Wiring Method 3P4L+PE
Frequency 50Hz/60Hz
Power Factor 1(Leading)~1(Lagging)
AC Maximum Current 167A
THDi ≤3% (Rated power)/td>
Max. Number Of Parallel Expansions 12
AC(off-grid)
Rated Power 100kW
AC Maximum Current 167A
AC Rated Voltage 400Vac
Wiring Method 3P4L+PE
Frequency 50Hz/60Hz
Unbalanced Load 100%
THDv <3% (Liner load)
Max. Number Of Parallel Expansions 5
Photovoltaic
Max. Input Power 50kW (Power 1.1 times overload)
Max. Input Current 100A
Short-circuit Current 150A
Max. Voltage 670Vdc
Input Voltage 200-670Vdc
MPPT Path 0~3
System
Dimensions(W*D*H) 1850*1265*2250mm
Weight ≈2800±100kg
Max. Efficiency ≥87%(TBD)
Air Conditioner Power 3kW (Cooling), 1kW (Heating)
Temperature -20~50℃(Derating above 40℃)
Humidity 0~95%(Non-condensing)
Ingress protection IP55
Anti-corrosion Grade C3
Cooling System Fan Cooling
Noise ≤75dB
Elevation 3000m(Derating above 2000m)
Display Touch screen
Fire Protection Aerosol/Perfluorohexanone
Communication Ethernet/4G/RS485
Certification CQC, CE, TUV
